OIS Four-axis Anti-Shake Test Shaker Plus

OIS Four-axis Anti-Shake Test Shaker Plus

Product number：WY-OIS60
brand：WYLAB
Product description: The four-axis OIS test vibration table plus is a high-precision large-angle vibration test platform developed by our company. It has rotational vibration and translational vibration, and can li
INQUIRY

产品简介FEATURES：
四轴OIS测试振台plus，是我司开发的一款高精度大角度振动测试平台，具备旋转振动及平移振动，并且可以使旋转、平移联动。使用 MCU 控制，液晶屏显示。内部使用陀螺仪实时反馈电路，可精确控制振动的角度和频率。可应用于手机、数码相机、摄相头模组的防抖功能测试。
The Four-Axis OIS Test Vibration Table is a high precision large angle vibration test platform developed by our company, It has rotational vibration and translation vibration, and can make rotation and translation linkage. Use MCU control, LCD display. The gyroscope real-time feedback circuit is used internally to precisely control the angle and frequency of the vibration. Anti-shake function test for mobile phones, digital cameras, and camera modules.

技术参数PARAMETERS：

供电电源 Power supply	DC 24V 3A
频率范围 Frequency range	2Hz - 10Hz
振动角度 Angle of vibration	±0.1°- ±3°（2-10Hz） ±3.1°- ±5°（2-4Hz）
振动距离 Distance of vibration	±0.5mm- ±2.5mm（2-10Hz） ±3mm- ±5mm（2-6Hz） ±5.5mm- ±10mm（2-4Hz）
频率分辨率 Frequency resolution	0.1 Hz
角度分辨率 Angle resolution	0.1°
距离分辨率 Distance resolution	0.5mm
最大承重 Max. load	单边1000g

备注：
1.振台使用应水平放置。
2.重负载工况时应保证负载平衡。
Postscript：
1.Shaking table should be placed horizontally in use.
2.Load balance should be guaranteed under heavy load conditions
